HAIFEI Welding Machine Catalogs
The complete Haifei product catalog introduces Wuxi Haifei Intelligent Equipment Co., Limited, its manufacturing capability, main welding technologies, equipment categories and industrial applications.
The catalog provides general product and application information. Final machine specifications depend on the workpiece, material, welding position, production output, tooling, control functions and factory utility requirements.
Download Complete Product Catalog
Product Catalogs by Welding Process
Diffusion Welding Machine
The diffusion welding machine catalog covers equipment for laminated copper foils, flexible copper busbars, copper braided connectors, aluminium conductors and other current-carrying components.
Spot Welding Machine
This catalog introduces HAIFEI medium-frequency DC and AC welding equipment designed for spot and projection welding applications.
Download Spot Welding Machine Catalog
Capacitor Discharge Welding Machine
This catalog covers capacitor discharge spot and projection welding machines, sometimes referred to as energy storage welding machines.
Download Capacitor Discharge Welding Machine Catalog
Seam Welding Machine
This catalog covers resistance seam welding equipment for continuous, overlapping or intermittent weld seams.
Download Seam Welding Machine Catalog
Ultrasonic Welding Machine
This catalog introduces ultrasonic metal welding equipment for copper and aluminium wires, terminals, wire harnesses, conductive foils and selected electrical components.
Download Ultrasonic Welding Machine Catalog
Welding Automation and Custom Equipment by Industry
HAIFEI develops welding workstations, multi-station equipment and automatic production lines around the customer's workpiece and production process.
Industry documents may include application examples, welding processes, workstation structures, feeding methods, automation functions and typical quality-control requirements.
Download Custom Welding Equipment Brochure
Certifications & Intellectual Property
Access HAIFEI's ISO 9001 quality management system certificate, CE compliance documents, patent certificates and computer software copyright registrations. Each document should be reviewed according to its stated holder, scope, certificate number and validity period.
ISO 9001 Quality Management System
Wuxi Haifei Welding Equipment Co., Ltd. maintains a quality management system certified to GB/T 19001-2016 / ISO 9001:2015.
The certified scope covers the manufacturing of resistance welding machines, specifically medium-frequency inverter DC spot welding machines.
This management system certification relates to the manufacturing activities stated on the certificate and should not be interpreted as individual product certification.
CE Compliance Documents
Download compliance documents for selected Haifei welding machine series. Each document identifies the applicable product, model range, reference standards, certificate number and validity period.
Invention Patents
Patents covering original welding processes, production methods and automated manufacturing systems developed by Haifei.
Computer Software Copyrights
Software copyright registrations covering independently developed welding control, parameter management, production monitoring and automation system software.
Utility Model Patents
Patents covering practical improvements to welding machines, fixtures, pressure mechanisms, electrode assemblies and automation equipment.
Design Patent Certificate
Patents protecting the original industrial appearance and structural design of selected Haifei welding equipment.
How to Select and Use a Document?
Use the complete product catalog when you need a general overview of HAIFEI equipment.
Use a product category catalog when the required welding process is already known.
Use an industry brochure when you are evaluating a customized workstation or automatic production line for a particular component.
Before using a conformity document, confirm that the equipment name and model are included in the document scope.
Catalog information does not replace the final quotation, approved technical agreement, machine drawing or project-specific compliance file.
Cannot Find the Document You Need?
Some specifications, installation manuals, electrical drawings and project files are not published publicly because they are linked to a specific machine configuration or customer project.Send us:
- Equipment or application name
- Complete model
- Machine serial number, if applicable
- Required document
- Destination country
- Customer company name
- Equipment nameplate photograph, if available
Contact HAIFEI Technical Support
FAQ About HAIFEI Catalogs and Certificates
Q: Which document should I download first?
A: Download the complete HAIFEI product catalog if you are reviewing the full equipment range. If the required welding process is already known, select the corresponding product category catalog.
Q: Are the specifications in a catalog final?
A: No. Catalog specifications describe general equipment ranges. The final configuration is determined by the workpiece, material, welding dimensions, tooling, production target and technical agreement.
Q: Does one CE document apply to every HAIFEI machine?
A: No. Each document has a defined product name and model range. Customized equipment or models not listed on the document require separate confirmation.
Q: Can I download an industry automation brochure?
A: Available industry brochures can be downloaded from the corresponding section. If a document has not yet been published, send the workpiece and industry information to request relevant project materials.
Q: Can HAIFEI provide an operation manual or electrical drawing?
A: These files are normally linked to a specific machine or order. Provide the model, serial number or HAIFEI order reference so that the correct version can be identified.
Q: Can I request a certificate for supplier qualification?
A: Yes. Send the equipment model and required document type. The customer should confirm whether the document scope and validity meet its own qualification requirements.
